AF-TC480

AF-TC480

Sale Sold out

This drone-mounted multi-spectral integrated imaging system is equipped with a standard aviation gimbal, offering excellent shock resistance and stability, along with broad compatibility. The system highly integrates ultraviolet, visible light, and laser ranging modules, supporting 1–10× fusion optical zoom and 120× hybrid zoom capability in the visible light spectrum. Through its multi-functional integrated design, it enables collaborative operation of multi-spectral imaging technologies, allowing for joint diagnosis and comprehensive analysis of targets.

View full details
  • Specifications
  • Downloads
    • Ultraviolet light wavelength range 240~280 nm
    Discharge sensitivity 1Pc @10 m
    RIV sensitivity 3.6 dBμV(RIV) @ 1 MHz@10 m
    Ultraviolet sensitivity 3.0×10-18 watt/cm2
    Field of view angle 20° ×11.2°
    Gain adjustment 0-100%
    Visible light Field of view 6.2°— 65°
    Angle Sensitivity 0.1 Lux
    Sensor size 3.2 — 33.6mm
    Digital zoom 10 times optical zoom, 12 times digital zoom
    Size 110×83×58mm

    AF-TC480

    * All performance data in the foregoing pages are theoretical values obtained by UAVCrafts® internal laboratories through tests carried out under particular conditions.
